Receiver Nad T754

Descripción

Receiver Nad T754 modelo top de linea
AV SURROUND SOUND RECEIVER T 754
Amplifier Section
Power output Stereo Mode
(8 ohms within rated distortion) 2 x 90W (19.5 dBW)
IHF dynamic power; 8 ohms 2 x 150W (21.7 dBW)
IHF dynamic power; 4 oh ms 2 x 200W (23 dBW)
Power output Surround Mode 6 x 70W (18.45 dBW)
Total harmonic distortion at rated power 0.08%
IM distortion at rated power 0.08%
Damping factor 8 ohms 60
Input sensitivity and impedance 400mV / 50k ohms
Frequency response 5 to 20,000 Hz ±0.8dB
Signal/noise ratio; ref rated power / 8 ohms (A-WTD) >90dB
Signal/noise ratio; ref 1W / 8 ohms (A-WTD) >80dB
Remote Control HTR 2 / ZR 2
Tuner Section
Input sensitivity Mono 16.1dBf
50dB Stereo: 36.1dBf
Harmonic Distortion; FM Mono 0.25%
Harmonic Distortion; FM Stereo 0.5%
Signal / noise; Mono 60dB
Signal / noise; Stereo 55dB
Stereo separation at 1kHz 40dB
Frequency Response; ± 1.5dB 30Hz - 15kHz
Physical Specifications
Dimensions (W x H x D) "
(435 x 170 x 423 mm)
Net Weight 45.1 lbs (20.5 kg)
Shipping Weight 52.8 lbs (24.0 kg)
